Cable Granulator
MACHTEK RECO 200
Industrial cable granulator with automatic dry separation. Processes mixed copper and aluminium cables, producing clean metal granulate with purity up to 99.9%. Compact all-in-one design, easy to operate and maintain.
Capacity150 – 300 kg/h
Total power28 kW
Metal purityup to 99.9%
Max wire diameter4.5 mm
Technical Specifications
| Model | MACHTEK RECO 200 |
|---|---|
| Type | Industrial cable granulator with automatic dry separation |
| Capacity | 150 – 300 kg/h (depending on cable type) |
| Input material | Copper & aluminium cables with PVC, PE, XLPE or rubber insulation |
| Max wire diameter | 4.5 mm |
| Metal purity | up to 99.9% |
| Total installed power | 28 kW |
| Voltage | 400 V, 50 Hz, 3-phase |
| Separation | Vibro-pneumatic gravity table |
| Granulate size | 3 – 5 mm |
| Hopper opening | 190 × 410 mm |
| Dust collection | Integrated cyclone + bag filter |
| Dimensions (L×W×H) | 4400 × 2700 × 2450 mm |
| Control system | PLC with touch panel |
Materials & Applications
- Copper cables with PVC, PE, XLPE or rubber insulation
- Aluminium cables
- Communication and data cables
- Automotive wiring harnesses
- Scrap copper wire from construction and demolition
Performance
Performance depends on cable type, size distribution and material purity.
| Cable type | Throughput | Purity |
|---|---|---|
| Mixed copper cables | 150–300 kg/h | 99.9% |
| Thin communication cables | 150–200 kg/h | 99%+ |
| Aluminium cables | 150–250 kg/h | 99%+ |
| Automotive harnesses | 150–250 kg/h | 99.9% |
Request a Quote — RECO 200
